Tanks for flammable liquid waste

Flammable liquid waste materials require meticulous care and advanced storage and management solutions.

CGH Tanks for Flammable Liquid Waste – Safety You Can Rely On

CGH tanks are equipped with cathodic protection and anti-corrosion coatings, as well as optional heating systems and thermal insulation.

Our structures operate effectively within a wide temperature range from -10°C to +150°C.

Our structures are equipped with agitator nozzles and appropriate service manholes.

We design tanks according to the specific needs of our customers.

Environmental protection through complete leak prevention

Maintaining stable storage conditions across the required temperature range

Safe handling of highly flammable substances

Reducing explosion risk with advanced safety and protection systems

Description:

Above-ground, vertical, single-wall tanks made of S235 carbon steel
Tanks mounted on six support legs, fitted with DN400 mixer nozzles and two DN800 manholes

Capacity:

100 m³, diameter: 2900 mm.

Medium:

Liquid flammable waste

Manufacturing standard:

AD 2000

Operating pressure:

Up to 0.5 bar

Operating temperature:

-10°C / +150°

Optional equipment
